Orbea Rallon X30

Orbea Rallon X30

The 2012 Orbea Rallon X30 is a full suspension bike designed for all-mountain riding. It has 26-inch wheels, an aluminum frame, 160mm of travel, and entry-level components.

Booking SKU FS01


Product Category Bikes
Brand Orbea
Model Rallon X30
Size S, M, L
Color Yellow, Teal Green


Brakes Shimano M506 Hydraulic Disc
Cassette Shimano HG50 11-36t 10-Speed
Chain KMC X10
Comfort rating 0
Country of origin Spain
Crankset Race Face Aeffect 22x36t Boost w/Bashguard
Design rating 0
Features – The Rallon C9-12 pivot system is based around a concentric pivot at the rear axle. It is simpler, lighter, and stiffer. This system is compatible with standard quick release and 12x142mm thru-axle rear hubs. The concentric pivot design also allows for a stronger, quieter post-mount disc brake attachment. – The Rallon bottom bracket shell features removable ISCG 05 chainguide tabs to allow you the ability to mount a chain retention device if you choose. It is the current standard for mount design, and it is possible to customize the level of chain retention with readily available aftermarket systems. – The Downtube Cable Highway keeps things tidy and simple on the Rallon. The cables run along the upper part of the downtube before looping gently, near the pivot point, towards the rear derailleur and rear brake. This routing system looks great, and it prevents cable rub and unwanted bulging when the suspension system moves through its travel range. This system increases performance and decreases maintenance. – The Direct Post Mount allows the disc brake caliper to bolt directly to frame without the use of an adapter. It is a simpler, stronger, and lighter system this way. It also serves to minimize vibration and, therefore, unwanted brake noise. The Direct Post Mount system on the Rallon is designed for use with 180mm or larger rotors.
Features rating 0
Fork type Fox 34 Float Performance 160 FIT4 3-Position QR15
Frame type Orbea Hydroformed triple butted alloy. Advanced Dynamics 160mm travel suspension. C-Boost 12×148 rear axle. Hollow linear ratio rocker arm. Pure Enduro geometry II. Downtube cable highway routing
Front derailleur Shimano SLX M677 Direct mount
Headset Orbit ZS 1″-1/2 Semi-Integrated
Manufacturer comments Enduro racing is hot, but purpose-built race bikes are few and far between, especially ones that can play double-duty like the Rallon X30. Not just one of the fastest bikes on the Enduro World Series, it’ll leave your riding buddies behind on the weekend loop too. Complete with Fox suspension front and rear, along with a capable Shimano SLX drivetrain, the X30 is one of the best values available when it comes to a pure enduro steed. The Rallon gives you a few precious seconds to write your own story. Grab a few extra breaths at the top of the climb. Whip instead of scrub. Knock your buddy off the leader board. Take the fun line instead of the easy line. Pull a snack from your pack or post a pic online. On the Rallon X30, sometimes a few seconds can seem like all the time in the world.
Material Alloy
Overall rating 0
Performance rating 0
Rear derailleur Shimano SLX GS Shadow Plus
Recommended for Recreational enduro riding
Release date 2012-09-06T16:00:00.000Z
Rims type Mach1 Klixx 23c Tubeless Ready wheelset
Saddle Selle Royal J-2062 Trail Custom
Shifters Shimano SLX M670 I-Spec
Shock type Fox Float DPS Performance 3-Position custom tune 215x63mm
Stem Race Face Ride
Year 2012
